| PartNumber | LSUGC202XA |
| Znamka | ALPS |
| Velikost | 8.9 |
| Aplikacija | |
| Resolucija | 640×240 |
| Sestava | LCM |
| Svetlost | 160 |
| CR | 3:1 |
| Barve | Monochrome |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel Data |
| znamka plošče | ALPS |
| panelni model | LSUGC202XA |
| vrsta plošče | STN-LCD , LCM |
| velikost plošče | 8.9 inch |
| resolucija | 640×240 , HVGA |
| način prikaza | STN, Blue mode |
| aktivno območje | 211.18×79.18 mm |
| oris | 270.2×112.2 mm |
| površino | |
| svetlost | 160 cd/m² (Typ.) |
| kontrastno razmerje | 3 : 1 (Typ.) |
| barve zaslona | Monochrome |
| odzivni čas | 250/120 (Typ.)(Tr/Td) |
| vidni kot | 30/30/15/30 (Min.)(CR≥10)(L/R/U/D) |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel Data (4-bit), 12 pins |
