| PartNumber | LD089WU1-SM01 |
| Znamka | LG Display |
| Velikost | 8.9 |
| Aplikacija | PAD |
| Resolucija | 1920×1200 |
| Sestava | LCM |
| Svetlost | 360 |
| CR | 800:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka plošče | LG Display |
| panelni model | LD089WU1-SM01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.9 inch |
| resolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 191.52×119.7 mm |
| oris | 203.4×135.85×5.25 mm |
| površino | Hard coating |
| svetlost | 360 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S5PWLEDWithout Driver |
| signalni vmesnik | MIPI (4 data lanes), 45 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
| B089AW01 V1 | AUO | 8.9 | 1024×600 |
| CLAA089NA0BCW | CPT | 8.9 | 1024×600 |
| HSD089IFW1-B00 | HannStar | 8.9 | 1024×600 |
| HSD089IFW3-A00 | HannStar | 8.9 | 1024×600 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LD089WX1-SL03 | LG Display | 8.9 | 1280×768 |
| LP089WS1-TLA1 | LG Display | 8.9 | 1024×600 |
| LQ089B1LS11 | SHARP | 8.9 | 1280×600 |
| LT089AC29000 | TOSHIBA | 8.9 | 1280×768 |
| LTM09C362 | TOSHIBA | 8.9 | 1024×600 |
| A090PAN01.0 | AUO | 9.0 | 900×1440 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| CLAA070WP03 | CPT | 7.0 | 800×1280 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LD083WU1-SPA3 | LG Display | 8.3 | 1200×1920 |
| LQ101R1SX03 | SHARP | 10.1 | 2560×1600 |
| M101NWWB R8 | IVO | 10.1 | 1280×800 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
