| PartNumber | VVX09F035M20 |
| Znamka | Panasonic |
| Velikost | 8.9 |
| Aplikacija | PAD |
| Resolucija | 1920×1200 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | Panasonic |
| panelni model | VVX09F035M20 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.9 inch |
| resolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | IPS-Pro, Normally Black, Transmissive |
| aktivno območje | 191.52×119.7 mm |
| oris | 203.5×135.9×4.8 mm |
| površino | Hard coating |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (6-bit + Dithering), CIE193150% |
| odzivni čas | 30 (Max.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Min.)(CR≥80)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S5PWLEDWithout Driver |
| signalni vmesnik | eDP (2 Lanes), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
