| PartNumber | HV089WU1-1E0 |
| Znamka | HYDIS |
| Velikost | 8.9 |
| Aplikacija | PAD |
| Resolucija | 1920×1200 |
| Sestava | LCM |
| Svetlost | 450 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka plošče | HYDIS |
| panelni model | HV089WU1-1E0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.9 inch |
| resolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | HFFS, Normally Black, Transmissive |
| aktivno območje | 191.52×119.7 mm |
| oris | 203.5×135.9×5 mm |
| površino | Antireflection |
| svetlost | 450 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (6-bit + Hi-FRC) |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S5PWLEDWithout Driver |
| signalni vmesnik | MIPI (4 data lanes), 45 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
| A089SW01 V0 | AUO | 8.9 | 1024×600 |
| B089AW01 V0 | AUO | 8.9 | 1024×600 |
| HV089WU1-1E0 | HYDIS | 8.9 | 1920×1200 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LJ640U35 | SHARP | 8.9 | 640×400 |
| LT089AC29000 | TOSHIBA | 8.9 | 1280×768 |
| LTM09C362 | TOSHIBA | 8.9 | 1024×600 |
| N089A1-L01 | Innolux | 8.9 | 1280×768 |
| N089L6-L03 | Innolux | 8.9 | 1024×600 |
| HJ101IA-01I | Innolux | 10.1 | 1280×800 |
| HT121WX2-210 | HYDIS | 12.1 | 1280×800 |
| LD070WU2-SM01 | LG Display | 7.0 | 1200×1920 |
| LP079X01-SMAV | LG Display | 7.9 | 768×1024 |
| LPM089A001A | JDI | 8.9 | 2560×1600 |
| LQ101R1SX01A | SHARP | 10.1 | 2560×1600 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| TFT08925601600 | SEBO | 8.9 | 2560×1600 |
