| PartNumber | HST043BOH57-40AV0 |
| Znamka | Other |
| Velikost | 4.3 |
| Aplikacija | PND |
| Resolucija | 480×272 |
| Sestava | LCM |
| Svetlost | |
| CR | 200:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | No Brand |
| panelni model | HST043BOH57-40AV0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 4.3 inch |
| resolucija | 480(RGB)×272 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 95.04×53.856 mm |
| oris | 105.7×67.25 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | 200:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193162% |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 40/40/60/15 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S1PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 8-bit), 40 pins |
| vhodna napetost | 1.8/2.8V (Typ.)(VDD/VCI) |
| rohs: | |
| aplikacija | PND |
| 43WQW4T | SII | 4.3 | 480×272 |
| 43WVF3A | SII | 4.3 | 480×800 |
| AMS427GL34-1 | Samsung | 4.3 | 480×800 |
| BT043NHME601 | BOE | 4.3 | 360×600 |
| HST043BOH57-40AV0 | Other | 4.3 | 480×272 |
| LH430WV3-SH02 | LG Display | 4.3 | 480×800 |
| LQ043T1DH42 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03A | SHARP | 4.3 | 480×272 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01B | SHARP | 4.3 | 480×800 |
| AT043TN25 V.2 | Innolux | 4.3 | 480×272 |
| CLAA048LA0BCW | CPT | 4.8 | 800×480 |
| DLC0430LZG-T | Other | 4.3 | 480×272 |
| DLC0500EZG-T-6 | Other | 5.0 | 800×480 |
| LB050WQ3-TD04 | LG Display | 5.0 | 480×272 |
| LMS430HF26 | Samsung | 4.3 | 480×272 |
| LMS500HF13-002 | Samsung | 5.0 | 480×272 |
| LQ036T1DG01 | SHARP | 3.6 | 272×480 |
| LQ043T3DX0F | SHARP | 4.3 | 480×272 |
| LR430RC9601 | Innolux | 4.3 | 480×272 |
