| PartNumber | DLC0500EZG-T-6 |
| Znamka | Other |
| Velikost | 5.0 |
| Aplikacija | PND |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 270 |
| CR | 500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | DLC |
| panelni model | DLC0500EZG-T-6 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 108×64.8 mm |
| oris | 121.1×76.2×5.05 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 270 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193150% |
| odzivni čas | 20 (Typ.)(Tr+Td) |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 6S2PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 8-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PND |
| 35HVE0H | SII | 3.5 | 320×480 |
| 43WQW4H | SII | 4.3 | 480×272 |
| 43WQW4T | SII | 4.3 | 480×272 |
| LB043WQ1-TD01 | LG Display | 4.3 | 480×272 |
| LB050WQ3-TD04 | LG Display | 5.0 | 480×272 |
| LMS480KC01 | Samsung | 4.8 | 800×480 |
| LMS500HF04-002 | Samsung | 5.0 | 480×272 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LQ043T3DX0F | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
