| PartNumber | LH430WV3-SH02 |
| Znamka | LG Display |
| Velikost | 4.3 |
| Aplikacija | MPH |
| Resolucija | 480×800 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 800:1 |
| Barve | |
| Osvetlitev ozadja | No B/L |
| Vmesnik | |
| znamka plošče | LG Display |
| panelni model | LH430WV3-SH02 4 Compatible model |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 4.3 inch |
| resolucija | 480(RGB)×800 , WVGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 56.16×93.6 mm |
| oris | 59.16×100.85 mm |
| površino | Without Polarizer |
| globina stekla | 0.20+0.20 mm |
| transmisivnost | 4.4% (Typ.)(with Polarizer) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | , CIE193172% |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| voznik ic | COG Suggest HX8369-A, LG4572B, LG4573B |
| aplikacija | MPH |
