| PartNumber | DMC-16117A |
| Znamka | Kyocera |
| Velikost | 2.4 |
| Aplikacija | |
| Resolucija | 16×1 |
| Sestava | LCM |
| Svetlost | |
| CR | |
| Barve | Monochrome |
| Osvetlitev ozadja | No B/L |
| Vmesnik | CPU |
| znamka plošče | OPTREX |
| panelni model | DMC-16117A |
| vrsta plošče | TN-LCD , LCM |
| velikost plošče | 2.4 inch |
| format prikaza | 16 characters × 1 lines |
| način prikaza | TN, Reflective |
| prikazne pisave | 5×8 dots |
| velikost znakov | 3.2×5.95 mm |
| višina znakov | 3.75×5.95 mm |
| aktivno območje | 59.4×5.95 mm |
| območje okvirja | 64.5×13.0 mm |
| oris | 80×36×10 mm |
| svetlost | |
| kontrastno razmerje | 3.5:1 (Typ.)(Reflective) |
| barve zaslona | Monochrome |
| odzivni čas | 180/130 (Typ.)(Tr/Td) |
| tip svetilke | No B/L |
| signalni vmesnik | 8-bit parallel, 14 pins |
| vhodna napetost | 5.0V (Typ.) |
| A024CN03 V2 | AUO | 2.4 | 480×234 |
| ACM019A | Other | 2.4 | 128×64 |
| DMC-16105NY-LY-ANN | Kyocera | 2.4 | 16×1 |
| DMC-16117A | Kyocera | 2.4 | 16×1 |
| DMC-16202NY-LY-BJE-BLN | Kyocera | 2.3 | 16×2 |
| DMC-16230NY-LY-EEE-EGN | Kyocera | 3.8 | 16×2 |
| FX020410DNSWBG01 | Data Image | 2.4 | 480×234 |
| LMS245DC08 | Samsung | 2.4 | 480×360 |
| LS024Q8DD92 | SHARP | 2.4 | 240×320 |
| LTM024DC9B | TOSHIBA | 2.4 | 240×320 |
| DLC0270CUOF | Other | 2.7 | 256×64 |
| LSUGC202XA | ALPS | 8.9 | 640×240 |
| LTD121KM2M | TOSHIBA | 12.1 | 1400×1050 |
| LTD121KM7K | TOSHIBA | 12.1 | 1400×1050 |
| OEL9M0083-R-E | Other | 0.96 | 128×64 |
| P50AD4 | E Ink | 5.0 | 320×234 |
| PD104VT3H1 | E Ink | 10.4 | 640×480 |
| TD043MTEA1 | TPO | 4.3 | 800×480 |
| TFD58W40-F | TOSHIBA | 5.8 | |
| UG-9616TSWCG02 | WiseChip | 0.69 | 96×16 |
