| PartNumber | LS024Q8DD92 |
| Znamka | SHARP |
| Velikost | 2.4 |
| Aplikacija | |
| Resolucija | 240×320 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 100:1 |
| Barve | 65K/262K |
| Osvetlitev ozadja | No B/L |
| Vmesnik | TTL |
| znamka plošče | SHARP |
| panelni model | LS024Q8DD92 |
| vrsta plošče | CG-Silicon , CELL |
| velikost plošče | 2.4 inch |
| resolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno območje | 36.72×48.96 mm |
| oris | 41.2×58 mm |
| površino | Hard coating (3H) |
| globina stekla | 0.50+0.50 mm |
| kontrastno razmerje | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| barve zaslona | 65K/262K |
| odzivni čas | 13/35 (Typ.)(Tr/Td) |
| vidni kot | 45/45/35/45 (Typ.)(CR≥3)(L/R/U/D) |
| voznik ic | Built-in uPD161831 |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 60 pins |
| vhodna napetost | 3.0/3.0V (Typ.)(VCC/VDC) |
