| PartNumber | DLC0283FZG-7 |
| Znamka | Other |
| Velikost | 2.8 |
| Aplikacija | MPH |
| Resolucija | 240×320 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | CPU/RGB |
| znamka plošče | DLC |
| panelni model | DLC0283FZG-7 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 2.8 inch |
| resolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 43.2×57.6 mm |
| oris | 50×70 mm |
| površino | |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Typ.) |
| barve zaslona | 262K , CIE193150% |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 5S1PWLEDWithout Driver |
| signalni vmesnik | CPU/RGB, 39 pins |
| vhodna napetost | 1.8/2.8V (Typ.)(IOVCC/VCC) |
