| PartNumber | H027QT01 |
| Znamka | AUO |
| Velikost | 2.7 |
| Aplikacija | MPH |
| Resolucija | 208×320 |
| Sestava | LCM |
| Svetlost | 60 |
| CR | 50:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | AU Optronics |
| panelni model | H027QT01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 2.7 inch |
| resolucija | 208(RGB)×320 |
| način prikaza | TN, Normally White, Transflective |
| aktivno območje | 36.816×56.64 mm |
| oris | 45.8×69.17 mm |
| površino | |
| svetlost | 60 cd/m² (Typ.) |
| kontrastno razmerje | 50:1 (Typ.)(Transmissive)20:1 (Typ.)(Reflective) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 10/30 (Typ.)(Tr/Td) |
| vidni kot | 45/45/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 2S2PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 60 pins |
| vhodna napetost | 3.3/5/5/3.3/12/-12V (Typ.)(DVCC/AVDD/AVDD1/AVDD2/VGH/VGL) |
| aplikacija | MPH |
