| PartNumber | LB020Q01-A1 |
| Znamka | LG Display |
| Velikost | 2.0 |
| Aplikacija | MPH |
| Resolucija | 320×240 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | |
| Barve | 262K |
| Osvetlitev ozadja | No B/L |
| Vmesnik | |
| znamka plošče | LG Display |
| panelni model | LB020Q01-A1 |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 2.0 inch |
| resolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 34.848×38.016 mm |
| oris | 39.2×48.3×0.9 mm |
| površino | Without Polarizer |
| globina stekla | 0.45+0.45 mm |
| transmisivnost | 22% (Typ.)(without Polarizer) |
| kontrastno razmerje | |
| barve zaslona | 262K (6-bit), CIE193145% |
| odzivni čas | 40 (Typ.)(Tr+Td) |
| vidni kot | 15/35/45/45 (Min.)(CR≥10)(L/R/U/D) |
| voznik ic | Suggest HD66774R, HD66772, HX8609A, HX8301A |
| aplikacija | MPH |
