| PartNumber | TM028HBHG02 |
| Znamka | Tianma |
| Velikost | 2.8 |
| Aplikacija | MPH |
| Resolucija | 240×320 |
| Sestava | LCM |
| Svetlost | 210 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | CPU |
| znamka plošče | TIANMA |
| panelni model | TM028HBHG02 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 2.8 inch |
| resolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 43.2×57.6 mm |
| oris | 50×69.2×4.4 mm |
| površino | Clear |
| svetlost | 210 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193165% |
| odzivni čas | 20 (Typ.)(Tr+Td) |
| vidni kot | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 1S4PWLEDWithout Driver |
| signalni vmesnik | 8/16-bit 6080/8080 parallel, 37 pins |
| vhodna napetost | (1.8/2.8)/2.8V (Typ.)(VCC/VCI) |
| aplikacija | MPH |
