| PartNumber | LM300W01-STA1 |
| Znamka | LG Display |
| Velikost | 30.0 |
| Aplikacija | DMPC |
| Resolucija | 2560×1600 |
| Sestava | LCM |
| Svetlost | 370 |
| CR | 600:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TMDS |
| znamka plošče | LG.Philips LCD |
| panelni model | LM300W01-STA1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 30.0 inch |
| resolucija | 2560(RGB)×1600 , WQXGA |
| način prikaza | S-IPS, Normally Black, Transmissive |
| aktivno območje | 641.28×400.8 mm |
| oris | 677.3×436.8 mm |
| površino | Antiglare (Haze 13%), Hard coating (3H) |
| svetlost | 370 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 8/6 (Typ.)(Tr/Td); 11 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 16 pcsCCFLEmbedded (Inverter) |
| signalni vmesnik | Dual Link TMDS, 45 pins |
| vhodna napetost | 18.0V (Typ.) |
| aplikacija | DMPC |
