| PartNumber | LTM300M1-P02 |
| Znamka | Samsung |
| Velikost | 30.0 |
| Aplikacija | DMPC |
| Resolucija | 2560×1600 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TMDS |
| znamka plošče | SAMSUNG |
| panelni model | LTM300M1-P02 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 30.0 inch |
| resolucija | 2560(RGB)×1600 , WQXGA |
| način prikaza | S-PVA, Normally Black, Transmissive |
| aktivno območje | 641.28×400.8 mm |
| oris | 677.3×436.8 mm |
| površino | Antiglare (Haze 44%), Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE1931100% |
| odzivni čas | 12 (Typ.)(Tr+Td); 6 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 16 pcsCCFLEmbedded (Inverter) |
| signalni vmesnik | Dual Link TMDS, 45 pins |
| vhodna napetost | 18.0V (Typ.) |
| aplikacija | DMPC |
