| PartNumber | NL10276AC30-03 |
| Znamka | NLT |
| Velikost | 15.0 |
| Aplikacija | DMPC |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 200 |
| CR | 200:1 |
| Barve | Full color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Analog |
| znamka plošče | NEC |
| panelni model | NL10276AC30-03 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 15.0 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 304.128×228.096 mm |
| oris | 350×265×20.5 mm |
| površino | |
| svetlost | 200 cd/m² (Typ.) |
| kontrastno razmerje | 200:1 (Typ.) |
| barve zaslona | Full color , CIE193142% |
| odzivni čas | 15/40 (Typ.)(Tr/Td) |
| vidni kot | 55/55/50/45 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 2 pcsCCFLEmbedded (Inverter) |
| signalni vmesnik | Analog RGB, 41 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | DMPC |
