| PartNumber | G070Y3-T01 |
| Znamka | Innolux |
| Velikost | 7.0 |
| Aplikacija | IA |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 600 |
| CR | 650:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | CMO |
| panelni model | G070Y3-T01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 156×82.8 mm |
| oris | 168×94×6.65 mm |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| svetlost | 600 cd/m² (Typ.) |
| kontrastno razmerje | 650:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193160% |
| odzivni čas | 5/11 (Typ.)(Tr/Td) |
| vidni kot | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 9S3PWLEDWithout Driver |
| signalni vmesnik | TTL (1 ch, 6-bit), 50 pins |
| vhodna napetost | 3.3/10.5/18/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikacija | IA |
