| PartNumber | G070Y2-T02 |
| Znamka | Innolux |
| Velikost | 7.0 |
| Aplikacija | CNS |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 600:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | CMO |
| panelni model | G070Y2-T02 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 152.4×91.44 mm |
| oris | 165×104×6.83 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) |
| barve zaslona | 262K/16.2M (6-bit / 6-bit + FRC), CIE193172% |
| odzivni čas | 5/11 (Typ.)(Tr/Td) |
| vidni kot | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S2PWLEDWithout Driver |
| signalni vmesnik | TTL (1 ch, 6/8-bit), 60 pins |
| vhodna napetost | 3.3/10/19/-6.8V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikacija | CNS |
