| PartNumber | DLC0350SZG |
| Znamka | Other |
| Velikost | 3.5 |
| Aplikacija | MPH |
| Resolucija | 480×640 |
| Sestava | LCM |
| Svetlost | 120 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | DLC |
| panelni model | DLC0350SZG |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 3.5 inch |
| resolucija | 480(RGB)×640 , VGA |
| način prikaza | Normally Black, Transflective |
| aktivno območje | 53.57×71.42 mm |
| oris | 64×85×5.2 mm |
| površino | |
| svetlost | 120 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| barve zaslona | 262K (6-bit), CIE193155% |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 6S1PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 40 pins |
| vhodna napetost | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| aplikacija | MPH |
