| PartNumber | ET028002DHU |
| Znamka | EDT |
| Velikost | 2.8 |
| Aplikacija | MPH |
| Resolucija | 240×320 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | CPU |
| znamka plošče | EDT |
| panelni model | ET028002DHU |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 2.8 inch |
| resolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 43.2×57.6 mm |
| oris | 50.5×69.6 mm |
| površino | |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K |
| odzivni čas | 10/15 (Typ.)(Tr/Td) |
| vidni kot | 75/70/75/55 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 1S4PWLEDWithout Driver |
| signalni vmesnik | CPU, 50 pins |
| vhodna napetost | 2.8V (Typ.) |
| aplikacija | MPH |
| 28QVF1H | SII | 2.8 | 240×320 |
| 28QVF2H | SII | 2.8 | 240×320 |
| BTL282440-310L | BOE | 2.8 | 240×400 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| TD028STEB1 | TPO | 2.8 | 240×320 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
| AMS369FG07-002 | Samsung | 3.7 | 480×800 |
| C0283QGLD-T | CMEL | 2.8 | 240×320 |
| CT022TN15 | Innolux | 2.2 | 176×220 |
| H335VVN01.0 | AUO | 3.4 | 480×854 |
| LH350WV2-SH02 | LG Display | 3.5 | 480×800 |
| LH550WF2-SD03 | LG Display | 5.5 | 1080×1920 |
| LMS241GF31 | Samsung | 2.4 | 240×320 |
| LQ034J1LX01 | SHARP | 3.4 | 320×480 |
| LQ043Y1DX02 | SHARP | 4.3 | 480×800 |
| LS055T3SX05 | SHARP | 5.5 | 1080×1920 |
