| PartNumber | LQ038J7DH52 |
| Znamka | SHARP |
| Velikost | 3.8 |
| Aplikacija | MPH |
| Resolucija | 320×480 |
| Sestava | LCM |
| Svetlost | 80 |
| CR | 60:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | SHARP |
| panelni model | LQ038J7DH52 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 3.8 inch |
| resolucija | 320(RGB)×480 , HVGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno območje | 52.8×79.2 mm |
| oris | 64.5×92.7 mm |
| površino | Hard coating (3H) |
| svetlost | 80 cd/m² (Typ.) |
| kontrastno razmerje | 60:1 (Typ.)(Transmissive)2:1 (Typ.)(Reflective) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 20/35 (Typ.)(Tr/Td) |
| vidni kot | 55/55/55/55 (Typ.)(CR≥2)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 39 pins |
| vhodna napetost | 5.0/3.3/15.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) |
| aplikacija | MPH |
