| PartNumber | DLC0350BMG-1 |
| Znamka | Other |
| Velikost | 3.5 |
| Aplikacija | MPH |
| Resolucija | 240×320 |
| Sestava | LCM |
| Svetlost | 100 |
| CR | 150:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | DLC |
| panelni model | DLC0350BMG-1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 3.5 inch |
| resolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno območje | 53.64×71.52 mm |
| oris | 64×85×3.13 mm |
| površino | Hard coating |
| svetlost | 100 cd/m² (Typ.) |
| kontrastno razmerje | 150:1 (Typ.)(Transmissive)6.5:1 (Typ.)(Reflective) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 6S1PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| vhodna napetost | 2.8/15/-10V (Typ.)(VCC/VGH/VGL) |
| aplikacija | MPH |
