| PartNumber | DLC0220KZG |
| Znamka | Other |
| Velikost | 2.2 |
| Aplikacija | MPH |
| Resolucija | 320×320 |
| Sestava | LCM |
| Svetlost | 200 |
| CR | 120:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | DLC |
| panelni model | DLC0220KZG |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 2.2 inch |
| resolucija | 320(RGB)×320 |
| način prikaza | ECB, Normally White, Transflective |
| aktivno območje | 39.36×39.36 mm |
| oris | 47.4×51.85×2.7 mm |
| površino | |
| svetlost | 200 cd/m² (Typ.) |
| kontrastno razmerje | 120:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| barve zaslona | 262K (6-bit), CIE193145% |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 45/45/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 3S1PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 39 pins |
| vhodna napetost | 3.0V (Typ.)(VDD) |
| aplikacija | MPH |
