| PartNumber | LS030B3UX07 |
| Znamka | SHARP |
| Velikost | 3.0 |
| Aplikacija | MPH |
| Resolucija | 240×400 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | CPU |
| znamka plošče | SHARP |
| panelni model | LS030B3UX07 |
| vrsta plošče | CG-Silicon , LCM |
| velikost plošče | 3.0 inch |
| resolucija | 240(RGB)×400 , WQVGA |
| način prikaza | Normally Black, Transmissive |
| aktivno območje | 38.88×64.8 mm |
| oris | 44.88×74.9 mm |
| površino | |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K , CIE193175% |
| odzivni čas | 11/24 (Typ.)(Tr/Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 1S5PWLEDWithout Driver |
| signalni vmesnik | CPU, 40 pins |
| vhodna napetost | 2.8/2.8V (Typ.)(VDDIO/VCC) |
| aplikacija | MPH |
