| PartNumber | VVX10T022N00 |
| Znamka | Panasonic |
| Velikost | 10.1 |
| Aplikacija | PAD |
| Resolucija | 2560×1600 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | Panasonic |
| panelni model | VVX10T022N00 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 10.1 inch |
| resolucija | 2560(RGB)×1600 , WQXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 216.96×135.6 mm |
| oris | 227.65×147.85×4.37 mm |
| površino | Hard coating |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 30 (Max.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S6PWLEDWithout Driver |
| signalni vmesnik | eDP (4 Lanes), 51 pins |
| vhodna napetost | 3.7V (Typ.) |
| aplikacija | PAD |
