| PartNumber | TX18D212VM0BAA |
| Znamka | KOE |
| Velikost | 7.0 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1280×768 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | KOE |
| velikost diagonale | 7.0 inch |
| slikovnih pik | 1280(RGB)×768 [WXGA] 213PPI |
| aktivno območje | 152.448(H)×91.4688(V) mm |
| območje okvirja | 154.5(H)×93.5(V) mm |
| svetilnost | 1000 cd/m² (Typ.) |
| smer pogleda | Symmetry |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| podpira barvo | 16.7M 72% NTSC |
| utež | 212g (Typ.) |
| hitrost sličic | 60Hz |
| model | TX18D212VM0BAA |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 164.4(H)×105(V) ×13.5(D) mm |
| zdravljenje | - |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| odzivni čas | 25 (Max.)(Tr+Tf) |
| način delovanja | IPS, Normally Black, Transmissive |
| Izvor svetlobe | WLED , 50K hours , With LED Driver |
| namenjen za | Industrial Outdoor High Brightness |
| plošča na dotik | Without |
