| PartNumber | G070VW01 V1 |
| Znamka | AUO |
| Velikost | 7.0 |
| Aplikacija | IA |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 500:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | AUO |
| panelni model | G070VW01 V1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 152.4×91.44 mm |
| oris | 170×111×8.5 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| odzivni čas | 12/18 (Typ.)(Tr/Td) |
| vidni kot | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (1 ch, 6/8-bit), 20 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
