| PartNumber | TV101WXM-AG0 |
| Znamka | BOE |
| Velikost | 10.1 |
| Aplikacija | Pad & Tablet |
| Resolucija | 800×1280 |
| Sestava | Assembly , a-Si TF |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 6S6P |
| Vmesnik | MIPI |
| proizvajalec | BOE |
| ime modela | TV101WXM-AG0 |
| velikost zaslona | 10.1 inch |
| vrsto zaslona | Assembly , a-Si TFT-LCD |
| število slikovnih pik | 800(RGB)×1280 (WXGA) 150PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 135.322 × 216.463 (H×V) |
| obris (mm) | 164 × 245.2 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Anti Fingerprint, Hard coating (7H) |
| svetilnost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | - |
| barvna globina | 16.7M 57% NTSC |
| osvetlitev ozadja | 6S6P WLED , 15K hours , No Driver |
| masa | 300g (Max.) |
| uporablja za | Pad & Tablet |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | PCAP |
| vrsto signala | MIPI (4 data lanes) , 51 pins Connector |
| napajanje z napetostjo | 3.3/5.5/-5.5V (Typ.)(VDDIO/AVDD/AVEE) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
