| PartNumber | SVA190WX05TB |
| Znamka | SVA-NEC |
| Velikost | 19.0 |
| Aplikacija | DMPC |
| Resolucija | 1440×900 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | SVA-NEC |
| panelni model | SVA190WX05TB |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 19.0 inch |
| resolucija | 1440(RGB)×900 , WXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 408.24×255.15 mm |
| oris | 428×278 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (6-bit + Hi-FRC), CIE193172% |
| odzivni čas | |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 4 pcsCCFL |
| signalni vmesnik | LVDS (2 ch, 8-bit) |
| rohs: | |
| aplikacija | DMPC |
