| PartNumber | TMS156WX1-02TC |
| Znamka | Tianma |
| Velikost | 15.6 |
| Aplikacija | DMPC |
| Resolucija | 1366×768 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No B/L |
| Vmesnik | LVDS |
| znamka plošče | AVIC |
| panelni model | TMS156WX1-02TC |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 15.6 inch |
| resolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 344.232×193.536 mm |
| površino | |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193160% |
| odzivni čas | 2/6 (Typ.)(Tr/Td) |
| vidni kot | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| signalni vmesnik | LVDS (1 ch, 8-bit), 30 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | DMPC |
