| PartNumber | HSD190MGW1-B00 |
| Znamka | HannStar |
| Velikost | 19.0 |
| Aplikacija | DMPC |
| Resolucija | 1440×900 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 700:1 |
| Barve | 16.2M |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | HannStar |
| panelni model | HSD190MGW1-B00 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 19.0 inch |
| resolucija | 1440(RGB)×900 , WXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 408.24×255.15 mm |
| oris | 428×278×19 mm |
| površino | Glare (Haze 0%), Hard coating (3H) |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 16.2M (6-bit + FRC), CIE193172% |
| odzivni čas | 1.5/3.5 (Typ.)(Tr/Td) |
| vidni kot | 75/75/75/65 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 4 pcsCCFLWithout Driver |
| signalni vmesnik | LVDS (2 ch, 8-bit), 30 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | DMPC |
| HSD190ME12-A02 | HannStar | 19.0 | 1280×1024 |
| HSD190ME12-A10 | HannStar | 19.0 | 1280×1024 |
| HSD190ME13-A13 | HannStar | 19.0 | 1280×1024 |
| HSD190ME13-D10 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A00 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A01 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A03 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN6-A00 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN6-A01 | HannStar | 19.0 | 1280×1024 |
| HSD190MGW1-B00 | HannStar | 19.0 | 1440×900 |
| LM200WD3-TLC9 | LG Display | 20.0 | 1600×900 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LTM230HT09 | Samsung | 23.0 | 1920×1080 |
| LTM340YP02 | Samsung | 34 | 3440×1440 |
| M150EW01 V0 | AUO | 15.0 | 1280×720 |
| M190A1-L01 | Innolux | 19.0 | 1440×900 |
| M270HGE-L30 | Innolux | 27.0 | 1920×1080 |
| MV238QUM-N20 | BOE | 23.8 | 3840×2160 |
| NL128102AC23-01 | NLT | 15.4 | 1280×1024 |
| NL256204AM15-02A | NLT | 20.1 | 2560×2048 |
