| PartNumber | LP097QX2-SPAV |
| Znamka | LG Display |
| Velikost | 9.7 |
| Aplikacija | PAD |
| Resolucija | 1536×2048 |
| Sestava | LCM |
| Svetlost | 440 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | LG Display |
| panelni model | LP097QX2-SPAV |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 9.7 inch |
| resolucija | 1536(RGB)×2048 , QXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 147.456×196.608 mm |
| oris | 160.3×208.93 mm |
| površino | Glare (Haze 0%), Hard coating (3H), Antireflection |
| svetlost | 440 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (8-bit) |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | eDP (4 Lanes), 42 pins |
| vhodna napetost | 3.7V (Typ.) |
| aplikacija | PAD |
