| PartNumber | LP097QX1-SPA1 |
| Znamka | LG Display |
| Velikost | 9.7 |
| Aplikacija | PAD |
| Resolucija | 2048×1536 |
| Sestava | LCM |
| Svetlost | 440 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | LG Display |
| panelni model | LP097QX1-SPA1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 9.7 inch |
| resolucija | 2048(RGB)×1536 , QXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 196.608×147.456 mm |
| oris | 208.88×167.12×5.17 mm |
| površino | Glare (Haze 0%), Hard coating (3H), Antireflection |
| svetlost | 440 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (8-bit) |
| odzivni čas | 16 (Typ.)(G to G) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S6P×2CNWLEDWithout Driver |
| signalni vmesnik | eDP (4 Lanes), 51 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPA2 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC2 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC3 | LG Display | 9.7 | 2048×1536 |
| LP097QX2-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLA3 | LG Display | 9.7 | 1024×768 |
| LQ097L1JY02Z | SHARP | 9.7 | 2048×1536 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| HV101WU1-1E3 | HYDIS | 10.1 | 1920×1200 |
| HV121WX6-111 | HYDIS | 12.1 | 1280×800 |
| HX104X02-100 | HYDIS | 10.4 | 1024×768 |
| LTL075PL01-001 | Samsung | 7.5 | 1050×1400 |
| N101ICG-L21 Rev.C2 | Innolux | 10.1 | 1280×800 |
| Q101IRE-GB1 | Innolux | 10.1 | 1280×800 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
