| PartNumber | B116XAN01.0 |
| Znamka | AUO |
| Velikost | 11.6 |
| Aplikacija | PAD |
| Resolucija | 1366×768 |
| Sestava | LCM |
| Svetlost | 700 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka plošče | AUO |
| panelni model | B116XAN01.0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 11.6 inch |
| resolucija | 1366(RGB)×768 , WXGA |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno območje | 256.125×144 mm |
| oris | 267.17×157.31×4.74 mm |
| površino | |
| svetlost | 700 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Min.) |
| barve zaslona | 16.7M (8-bit), CIE193150% |
| odzivni čas | 30 (Max.)(Tr+Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 8S6PWLEDWithout Driver |
| signalni vmesnik | MIPI (4 data lanes), 45 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
