| PartNumber | HX104X02-100 |
| Znamka | HYDIS |
| Velikost | 10.4 |
| Aplikacija | PAD |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 340 |
| CR | 600:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | HYDIS |
| panelni model | HX104X02-100 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 10.4 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | AFFS+, Normally Black, Transmissive |
| aktivno območje | 210.4×157.8 mm |
| oris | 238.6×173.2×6.8 mm |
| površino | Antiglare, Antireflection |
| svetlost | 340 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193140% |
| odzivni čas | 36 (Typ.)(Tr+Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S6PWLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (1 ch, 6-bit), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
