| PartNumber | LM200WD3-TLC9 |
| Znamka | LG Display |
| Velikost | 20.0 |
| Aplikacija | DMPC |
| Resolucija | 1600×900 |
| Sestava | LCM |
| Svetlost | 250 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | LG Display |
| panelni model | LM200WD3-TLC9 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 20.0 inch |
| resolucija | 1600(RGB)×900 , HD+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 442.8×249.075 mm |
| oris | 462.8×272 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 1.1/3.9 (Typ.)(Tr/Td) |
| vidni kot | 85/85/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 2 stringsWLEDWithout Driver |
| signalni vmesnik | LVDS (2 ch, 8-bit), 30 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | DMPC |
