| PartNumber | LTM340YP02 |
| Znamka | Samsung |
| Velikost | 34 |
| Aplikacija | DMPC |
| Resolucija | 3440×1440 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 3000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | SAMSUNG |
| panelni model | LTM340YP02 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 34 inch |
| resolucija | 3440(RGB)×1440 |
| način prikaza | PVA, Normally Black, Transmissive |
| aktivno območje | 799.8×334.8 mm |
| oris | 811.5×357×18.1 mm |
| površino | Antiglare (Haze 2.3%), Hard coating (2H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 3000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), sRGB99% |
| odzivni čas | 14 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 4 stringsWLEDWithout Driver |
| signalni vmesnik | eDP (4 Lanes), 50 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | DMPC |
