| PartNumber | NL256204AM15-02A |
| Znamka | NLT |
| Velikost | 20.1 |
| Aplikacija | DMPC |
| Resolucija | 2560×2048 |
| Sestava | LCM |
| Svetlost | 850 |
| CR | 600:1 |
| Barve | Grayscale |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | NEC |
| panelni model | NL256204AM15-02A |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 20.1 inch |
| resolucija | 2560(LCR)×2048 , QSXGA |
| način prikaza | SA-SFT, Normally Black, Transmissive |
| aktivno območje | 399.36×319.49 mm |
| oris | 423.4×343.5×45.5 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 850 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) |
| barve zaslona | Grayscale (8-bit) |
| odzivni čas | 15/15 (Typ.)(Tr/Td) |
| vidni kot | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 12 pcsCCFLEmbedded (Inverter) |
| signalni vmesnik | LVDS (4 ch, 8-bit) |
| vhodna napetost | 12.0V (Typ.) |
| rohs: | |
| aplikacija | DMPC |
