| PartNumber | SP10Q010 |
| Znamka | KOE |
| Velikost | 3.8 |
| Aplikacija | IA |
| Resolucija | 320×240 |
| Sestava | LCM |
| Svetlost | 110 |
| CR | 20:1 |
| Barve | Monochrome |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel Data |
| znamka plošče | KOE |
| panelni model | SP10Q010 |
| vrsta plošče | FSTN-LCD , LCM |
| velikost plošče | 3.8 inch |
| resolucija | 320×240 , QVGA |
| način prikaza | STN, Black/White (Negative), Transmissive |
| aktivno območje | 76.79×57.59 mm |
| oris | 94.7×73.3×6 mm |
| površino | Glare (Haze 0%) |
| svetlost | 110 cd/m² (Typ.) |
| kontrastno razmerje | 20:1 (Typ.) |
| barve zaslona | Monochrome |
| odzivni čas | 150/350 (Typ.)(Tr/Td) |
| vidni kot | 80 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| pogostost | 75Hz |
| tip svetilke | 1S6PWLEDWithout Driver |
| signalni vmesnik | Parallel Data (4-bit), 20 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
