| PartNumber | LM050QC1T01 |
| Znamka | SHARP |
| Velikost | 5.0 |
| Aplikacija | IA |
| Resolucija | 320×240 |
| Sestava | LCM |
| Svetlost | 100 |
| CR | 30:1 |
| Barve | Color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel Data |
| znamka plošče | SHARP |
| panelni model | LM050QC1T01 |
| vrsta plošče | CSTN-LCD , LCM |
| velikost plošče | 5.0 inch |
| resolucija | 320(RGB)×240 , QVGA |
| način prikaza | STN, Normally Black, Transmissive |
| aktivno območje | 100.8×75.6 mm |
| oris | 134×100 mm |
| površino | |
| svetlost | 100 cd/m² (Typ.) |
| kontrastno razmerje | 30:1 (Typ.) |
| barve zaslona | Color |
| odzivni čas | 230/120 (Typ.)(Tr/Td) |
| vidni kot | 35/35/15/25 (Typ.)(CR≥5)(L/R/U/D) |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel Data (8-bit), 20 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
