| PartNumber | CLAP070WP03XG |
| Znamka | CPT |
| Velikost | 7.0 |
| Aplikacija | PAD |
| Resolucija | 800×1280 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No B/L |
| Vmesnik | LVDS |
| znamka plošče | CPT |
| panelni model | CLAP070WP03XG |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×1280 , WXGA |
| način prikaza | HFFS, Normally Black, Transmissive |
| aktivno območje | 94.2×150.72 mm |
| oris | 102.1×158.92×0.87 mm |
| površino | |
| globina stekla | 0.30+0.30 mm |
| transmisivnost | 3.66% (Typ.)(with Polarizer) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 16.7M (8-bit) |
| odzivni čas | 50 (Max.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| signalni vmesnik | LVDS (1 ch, 8-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
