| PartNumber | CLAF055WB41 TXX |
| Znamka | CPT |
| Velikost | 5.5 |
| Aplikacija | MPH |
| Resolucija | 720×1280 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 800:1 |
| Barve | |
| Osvetlitev ozadja | No B/L |
| Vmesnik | |
| znamka plošče | CPT |
| panelni model | CLAF055WB41 TXX 2 Compatible model |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 5.5 inch |
| resolucija | 720(RGB)×1280 , WXGA |
| način prikaza | HFFS, Normally Black, Transmissive |
| aktivno območje | 68.04×120.96 mm |
| oris | 70.44×128.56 mm |
| površino | Hard coating |
| globina stekla | 0.20+0.20 mm |
| transmisivnost | 5.0% (Typ.)(with APCF) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | , CIE193170% |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| voznik ic | Suggest ILI9881, OTM1284A-C1 |
| aplikacija | MPH |
| ACX567AKM-7 | SONY | 3.2 | 320×480 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| AMS347FF01 | Samsung | 3.5 | 360×640 |
| DLC0283FZG-7 | Other | 2.8 | 240×320 |
| LQ024B7UD01 | SHARP | 2.4 | 160×240 |
| LS038Y7DX01 | SHARP | 3.8 | 480×800 |
| LT032MDQ7000 | JDI | 3.2 | 360×480 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TM055XDHP10 | Tianma | 5.5 | 540×960 |
