| PartNumber | TM055XDHP10 |
| Znamka | Tianma |
| Velikost | 5.5 |
| Aplikacija | MPH |
| Resolucija | 540×960 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka plošče | TIANMA |
| panelni model | TM055XDHP10 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.5 inch |
| resolucija | 540(RGB)×960 , qHD |
| način prikaza | FFS, Normally Black, Transmissive |
| aktivno območje | 68.04×120.96 mm |
| oris | 72.14×130.86×1.95 mm |
| površino | Antiglare (Haze 42%) |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193170% |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 80Hz |
| tip svetilke | 5S2PWLEDWithout Driver |
| signalni vmesnik | MIPI (2 data lanes), 30 pins |
| vhodna napetost | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| aplikacija | MPH |
