| PartNumber | C090EAN04.1 |
| Znamka | AUO |
| Velikost | 9.0 |
| Aplikacija | Outdoor High Brightn |
| Resolucija | 1280×720 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AUO |
| model | C090EAN04.1 |
| velikost diagonale | 9.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1280(RGB)×720 [WXGA] 163PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 198.72(H)×111.78(V) mm |
| obris dim. | 212.2(H)×127.9(V) ×11(D) mm |
| območje okvirja | 202.02(H)×115.78(V) mm |
| zdravljenje | Antiglare |
| svetilnost | 900 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način delovanja | AHVA, Normally Black, Transmissive |
| podpira barvo | 16.7M 72% NTSC |
| Izvor svetlobe | WLED [8S3P] , 10K hours , W/O Driver |
| utež | TBD |
| namenjen za | Outdoor High Brightness Automotive Display |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (1 ch, 8-bit) , 40 pins FPC |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AA090ME01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| LTA090A220F | TOSHIBA | 9.0 | 800×480 |
| LTA090B400F | TOSHIBA | 9.0 | 800×480 |
| NL192108AC10-01D | NLT | 9.0 | 1920×1080 |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
