| PartNumber | TX23D12VM0CAA |
| Znamka | KOE |
| Velikost | 9.0 |
| Aplikacija | IA |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | HITACHI |
| panelni model | TX23D12VM0CAA |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 9.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 195×117 mm |
| oris | 236×135 mm |
| površino | Antiglare |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193160% |
| odzivni čas | 13/17 (Typ.)(Tr/Td) |
| vidni kot | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | CMOS (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.)(VDD) |
| aplikacija | IA |
