| PartNumber | AM-1024600LHMQW-16H |
| Znamka | AMPIRE |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1024×600 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | 6S6P |
| Vmesnik | LVDS |
| proizvajalec | AMPIRE |
| ime modela | AM-1024600LHMQW-16H |
| velikost zaslona | 10.1 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 1024(RGB)×600 (WSVGA) 117PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 222.72 × 125.28 (H×V) |
| obris (mm) | 235 × 145.8 × 7.3 (H×V×D) |
| površina okvirja (mm) | 225.92 × 128.48 (H×V) |
| zdravljenje | Antiglare |
| svetilnost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| vidni kot | 70/70/70/50 (Typ.)(CR≥10) |
| odgovor | 4/12 (Typ.)(Tr/Td) ms |
| dober pogled na | - |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 262K 47% NTSC |
| osvetlitev ozadja | 6S6P WLED , 20K hours , With LED Driver |
| masa | TBD |
| uporablja za | Industrial |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (1 ch, 6-bit) , 30 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
