| PartNumber | AM-1024600-070H |
| Znamka | Other |
| Velikost | 7.0 |
| Aplikacija | CNS |
| Resolucija | 1024×600 |
| Sestava | LCM |
| Svetlost | |
| CR | |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | Amson |
| panelni model | AM-1024600-070H |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 153.6×90 mm |
| oris | 165.75×105.39×3.7 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | |
| barve zaslona | 262K/16.7M (6-bit / 6-bit + Dithering) |
| odzivni čas | |
| vidni kot | |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 6/8-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | CNS |
