| PartNumber | AV080WSM-NW0 |
| Znamka | BOE |
| Velikost | 8.0 |
| Aplikacija | CNS |
| Resolucija | 1024×600 |
| Sestava | LCM |
| Svetlost | 600 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | BOE |
| panelni model | AV080WSM-NW0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.0 inch |
| resolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | ADS, Normally Black, Transmissive |
| aktivno območje | 176.64×99.36 mm |
| oris | 192.8×116.9 mm |
| površino | |
| svetlost | 600 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (6-bit + Hi-FRC), CIE193150% |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 3S10PWLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 8-bit), 40 pins |
| vhodna napetost | 3.3/11.5/18.0/-10.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplikacija | CNS |
