| PartNumber | PA050DT2 |
| Znamka | E Ink |
| Velikost | 5.0 |
| Aplikacija | CNS |
| Resolucija | 320×234 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 350:1 |
| Barve | Full color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Analog |
| znamka plošče | PVI |
| panelni model | PA050DT2 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.0 inch |
| resolucija | 320(RGB)×234 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 102.72×74.53 mm |
| oris | 127.4×92.8×19 mm |
| površino | Antiglare |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 350:1 (Typ.) |
| barve zaslona | Full color |
| odzivni čas | 15/30 (Typ.)(Tr/Td) |
| vidni kot | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 1 pcsCCFLEmbedded (Inverter) |
| signalni vmesnik | TFT Specific Analog RGB, 28 pins |
| vhodna napetost | 12.0V (Typ.)(LCD+Backlight) |
| aplikacija | CNS |
