| PartNumber | AG-320240A4FIQW-K9H-S(N)(R) |
| Znamka | AMPIRE |
| Velikost | 5.7 |
| Aplikacija | IA |
| Resolucija | 320×240 |
| Sestava | LCM |
| Svetlost | |
| CR | |
| Barve | Monochrome |
| Osvetlitev ozadja | WLED |
| Vmesnik | CPU |
| znamka plošče | AMPIRE |
| panelni model | AG-320240A4FIQW-K9H-S(N)(R) |
| vrsta plošče | FSTN-LCD , LCM |
| velikost plošče | 5.7 inch |
| resolucija | 320×240 , QVGA |
| način prikaza | STN, Transflective |
| aktivno območje | 115.185×86.385 mm |
| oris | 167×104.7×14.5 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | |
| barve zaslona | Monochrome |
| odzivni čas | 200/200 (Typ.)(Tr/Td) |
| vidni kot | 30/30/35/30 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 1S6PWLEDWithout Driver |
| signalni vmesnik | 8-bit 6080/8080 parallel, 24 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | IA |
